型号 功率（kVA） 输出电压（V_rms） 频率范围（Hz） 输出电流（A） 电压范围（V_DC） 电流范围（A_DC） 尺寸（mm）:宽×深×高 重量（kg）
PRO20-A05-4701 50 470 DC,0.001-200.0 100 ±665 ±150 800×1000×1950 415
PRO20-A10-4702 100 470 DC,0.001-200.0 200 ±665 ±300 800×1000×1950 490
PRO20-A15-4703 150 470 DC,0.001-200.0 300 ±665 ±450 800×1000×1950 565
PRO20-A20-4704 200 470 DC,0.001-200.0 400 ±665 ±600 800×1000×1950 640
PRO20-A25-4705 250 470 DC,0.001-200.0 500 ±665 ±750 800×1000×1950 715
PRO20-A30-4706 300 470 DC,0.001-200.0 600 ±665 ±900 800×1000×1950 790
PRO20-A35-4707 350 470 DC,0.001-200.0 700 ±665 ±1050 800×1000×1950 865
PRO20-A40-4708 400 470 DC,0.001-200.0 800 ±665 ±1200 800×1000×1950 940
PRO20-A45-4709 450 470 DC,0.001-200.0 900 ±665 ±1350 1400×1000×1950 1295
PRO20-A50-4710 500 470 DC,0.001-200.0 1000 ±665 ±1500 1400×1000×1950 1370
PRO20-A55-4711 550 470 DC,0.001-200.0 1100 ±665 ±1650 1400×1000×1950 1445
PRO20-A60-4712 600 470 DC,0.001-200.0 1200 ±665 ±1800 1400×1000×1950 1520
PRO20-A65-4713 650 470 DC,0.001-200.0 1300 ±665 ±1950 1400×1000×1950 1595
PRO20-A70-4714 700 470 DC,0.001-200.0 1400 ±665 ±2100 1400×1000×1950 1670
PRO20-A75-4715 750 470 DC,0.001-200.0 1500 ±665 ±2250 1400×1000×1950 1745
PRO20-A10-9001 100 900 DC,0.001-200.0 200 ±1272 ±300 800×1000×1950 490
PRO20-A20-9002 200 900 DC,0.001-200.0 200 ±1272 ±300 800×1000×1950 640
PRO20-A30-9003 300 900 DC,0.001-200.0 300 ±1272 ±450 800×1000×1950 790
PRO20-A40-9004 400 900 DC,0.001-200.0 400 ±1272 ±600 800×1000×1950 940
PRO20-A50-9005 500 900 DC,0.001-200.0 500 ±1272 ±750 1400×1000×1950 1370
PRO20-A60-9006 600 900 DC,0.001-200.0 600 ±1272 ±900 1400×1000×1950 1520
PRO20-A70-9007 700 900 DC,0.001-200.0 700 ±1272 ±1050 1400×1000×1950 1670
